The Gliderol Mini Roller Door requires less space above the door opening, making it ideal for flat roof garages or other garages that may have restricted space. The compact roll requires only 340mm of headroom, rather than the recommended 450mm for the full size roller door.
The Mini Roller doors are made to measure and available in all 18 attractive Plastisol finishes. They can be automatic or manual. The manual roller door is spring assisted, which makes it light and easy to open - minimum friction gives a smooth and quiet operation at all times.
The double-sided locking system and reinforced bottom rail will protect your home against intruders, whilst the durable weather seal on the underside of the door will prevent leaves and other materials from entering your garage.
> Twin solid locking bars for a secure closure.
> Highly durable, wipe clean finish:
Colour Options
White
Van Dyke Brown
Olive Green
Black
Burgundy
Navy Blue
Honesty
Goosewing Grey
Mushroom
Merlin Grey
Anthracite Grey
Zincalume
Ultramarine Blue
Mushroom BS10S19
Chartwell Green
Smooth mid grey inner face
Handle and Lock will be supplied as standard on manual and automatic doors.
Gliderol Roll In One Motor (complete with 2 handsets as standard):
All Gliderol residential operators are now compatible with the All in One motor. All in One is a smart, innovative home access system that allows you to control your home the way that suits your lifestyle. With one discrete, simple key, a click of a button can turn off your alarm and open or close your garage door.
In the case of a power faliure the Roll In One opener has a manual release cord to change the door to manual function.
The control box includes an internal courtesy LED light. This is activated during both the open and closing cycles and remain illuminated for approximately 60 seconds.
For additional security the Roll In One has an internal Piezo Siren that will beep briefly each time the door is used. The transmitter and receiver use the latest state of the art encryption technology where the coded transmission changes after each transmission with billions of unique combinations. One opener has the facility to store up to 15 individual handsets.
Only manually operated doors come with a central lock and key as standard, if this is required on a motorised door, please order as an additional accessory.
please note: The motor comes as retrofit. It is not inbuild into the axel and will need to be fitted by the customer.
Gliderol Mini Roll Technical Information
(Hand Operated) - 2100mm high
Side Room: 75mm
Head Room: 340mm
A: 25mm-100mm
B: 420mm
C: 150mm
D: 190mm
If recommended headroom is not available the door may still be installed, required headroom should be maintained
(n.b. some loss of opening height will occur and the roll of the door will be visible, but this may be disguised by a fascia).
• Domestic/Residential use - 10 years corrosion free on door panel excludes paint surface rubbing or fading. (Mini Roller door has 1 year total warranty cover).
1 year on the lock and face plate, spring, bottom roller, weatherseal and polyglide, if fitted by an authorised Gliderol Distributor or Gliderol Technician.
3 month warranty on spring tension.
• Industrial/Commercial use - 1 year on the lock and face plate, spring, bottom roller, weatherseal and polyglide, if fitted by an authorised Gliderol Distributor or Gliderol Technician. 3 month warranty on spring tension.
The manufacturer strongly recommends that all Gliderol products be serviced by an authorised Gliderol Distributor or Gliderol Technician every 12 months to ensure longevity of the products’ life. Failure to do this may result in any warranty being invalid.
Warranties of 2 years electrical, 5 years tubular motors, 6 years mechanical and 10 years paint finish apply to all Gliderol doors (except Mini Roller
Doors see above).
Garage doors should be inspected upon installation and viewed in natural daylight (not direct sunlight) from a standard distance of 3 metres to view their overall appearance. From this distance the door panel should appear free from visible marks or distortion, stains, blemishes, indentations or scuffs.
Only marks visible from a distance of more than 3 metres will be considered under warranty.
PRODUCT WARRANTY CONDITIONS
Warranty Conditions
1. Subject to the under mentioned specific limitations and exceptions, the Manufacturer warrants all new doors, motors and electronic components of its
manufacture to be free from defect in workmanship under normal use and service and further warrants all installation carried out by the Manufacturer or by its nominated installers to be free from defects and workmanship its obligations hereunder being limited to making good any such defect PROVIDED THAT notice of any claimed defect in material workmanship in or resulting from installation of any door shall have been given to the Manufacturer within the period from date of installation as prescribed in the schedule hereto.
2. This warranty does not apply to any defect, loss or damage arising or caused directly or indirectly by or as a result of;
(i) Any masonry rendered or other surfaces cracking or collapsing during installation of the door.
(ii) Any defect or deterioration of timber including drying out after installation.
(iii) Any weakening or collapse of the structure to which the doors are affixed occurring any time after installation.
(iv) Any damage to or deterioration in the condition of the doors occurring in transit by customer nominated or appointed carrier or occurring after delivery and prior to installation.
(v) Any defect (including defects in component parts or accessories) rising from or attributable to the failure to carry out normal preventive maintenance or adjustment.
(vi) To any additional defect damage or deterioration arising from or attributable to the operation of the door after it is known to be defective.
(vii) Any door being installed within 800 metres of the sea or other body of water of equivalent or greater salt concentration or in an area subject to industrial fall out.
(viii) Any fault or surge in customer’s electricity supply.
(x) The door striking an immovable object during travel.
(xi) Garage doors should be inspected upon delivery and viewed in natural light (not direct sunlight) from a standard distance of 3 metres to view their overall appearance. From this distance the door panel should appear free from marks or distortion, stains, blemishes, indentations or scuffs. If any marks are only visible within 3 metres they will not be considered under warranty.
3. Items excluded from warranty;
(i) Batteries
(ii) Fuses
(iii) Globes
(iv) Sensitivity adjustments
(iiv) Minor factory repairs
4. While Gliderol doors are long lasting and hard wearing under normal conditions this warranty does not extend to inherent defects in steel or other material used in the manufacture. The Manufacturer will however, procure and assign to the customer the benefit of the warranty of the manufacturer of the steel or other material.
5. If Manufacturer has at request of customer procured painting, powder-coating or other surface application to its product this warranty does not extend to such painting, powder-coating or other surface application. For this purpose Manufacturer at all times acts as agent of customer. Manufacturer may as a
service to the customer but without any legal obligation to do so, assist customer to obtain redress in respect of any defect.
6. The Manufacturer reserves the right to touch up on site the paint finish and or pre-painted surfaces on its range of garage doors but no responsibility will be taken for the possibility of any paint rubs, scuffing etc on the internal wash coat finish or external painted surface.
7. Proof of purchase MUST be provided to the manufacturer at time of warranty claim. If proof is not available any warranty may be invalid.
