Hormann Rollmatic OD with Horizontal glide rails (12 Colour Options) Insulated Roller door garage door Aluminium Hormann

01926 463 888


Hormann Rollmatic OD with Horizontal glide rails (12 Colour Options) Aluminium Roller door - insulated
Hormann
Hormann Look at our customer reviews on trustpliot
Roller door - insulated Aluminium GEAR TYPE: Roller Shutter

The Hormann RollMatic OD horizontal door is ideal for modernisation. The narrow design of the horizontal door allows fitting in the garage even in very tight spaces. The door's compact construction only requires a headroom of 60mm.

  • ProMatic electric operator included as standard with 2 handsets
  • Automatic door locking function
  • Only requires 60mm headroom, unique door movement
  • Made to measure for perfect fit
1
Choose Your Sizes
Web Price from: £1,322.40 Inc. VAT
£1,102.00 Ex. VAT

The Hormann Rollmatic OD comes with the standard ProMatic operator which is placed in a central position.

With the optionally available SupraMatic operator, your horizontal door opens faster and you can drive directly from the street into your garage. And you will wonder how you ever lived without convenience functions such as the additional opening height, e.g. to ventilate your garage, and being able to switch the operator lighting on and off with your hand transmitter.

A counterbalance system integrated in the side guides supports the operator during the opening and closing of the door and prevents damage to the operator mechanism.

The multiple spring assemblies and the double lifting cables prevent the door leaf from crashing to the floor in every position. In case of emergency, the door can be easily opened by hand. A crank handle is not necessary for this purpose for Rollmatic OD garage doors.

RollMatic doors are especially quiet and subject to minimum wear due to the standard operators with soft start and soft stop. The counterbalance system and the reliable automatic safety cut-out securely stops the door if it encounters an obstacle. For even more protection and safety, we recommend fitting a non-contact photocell.

For garages with a particularly low headroom, overhead garage doors RollMatic OD are especially suitable. The door curtain is guided under the ceiling through narrow side guides.

Domestic Use.

Smooth door travel

Twin rollers evenly and smoothly guide the door curtain under the ceiling. The narrow aluminium side guides are connected by stable corner diversions with small radii. Due to this compact design the overhead garage door RollMatic OD only requires a lintel of 60 mm.


Sealed on all sides

The elastic lip seal in the lintel area and brush seals in the side guides optimally seal the door curtain. The flexible EPDM bottom profile compensates for unevenness in the floor and seals the bottom edge of the door.

Integrated counterbalance

The multiple spring assemblies optimally balance the weight of the door curtain in every position. This preserves the operator mechanism and, together with the automatic safety cut-out of the operator, guarantees safe door operation. In addition, the integral catch safety device protects the door against crashing to the floor in case of a possible cable tear.

Space-saving operator fitting

The operator booms can either be installed on the right or the left horizontal side guide. This compact design does not require additional headroom.

Variable fitting


The vertical side guides and the fascia panel are supplied in the colour of the door as standard. Thus the door can also be fitted partially or completely in the opening. Using the optional retrofit fascias, the door is fitted in the reveal and at the same time covers unattractive gaps in the lintel and opening areas. Additional brickwork and plastering work are no longer required.

Retrofit fascia panels (for flush fitting)

> As cover for lintel and frame with flush-fitting installation and for renovations

> For use with doors up to LB max. 3150mm and LH max. 2700mm

Consisting of:

> 2 fascias, width 95mm, length 2800mm each

> 1 fascia, with 95mm, length 3200mm

> including additional fixing material for panel and door

> 2 plastic panel shoes (black)

Note: The vertical tracks and the fascia panel are pre-drilled at the factory if this fitting is selected.

ProMatic – the standard operator
• As standard with 4-button hand transmitter HSE 4 BS
• Query of the door position with optional hand transmitter HS 5 BS
• Adjustable ventilation slot
• Automatic door locking

SupraMatic − the supra-fast operator with many additional functions
• As standard with 5-button hand transmitter HS 5 BS
• Query of the door position
• Low power consumption
• Easy to program
• 2 × 7-segment display
• Adjustable ventilation slot
• Automatic door locking
• Operator cover made of brushed aluminium

Closing Edge Safety Device
All Hormann Roller garage doors over 500mm wide are fitted with an optical closing edge safety device as standard.  The device is factory fitted in the bottom profile and ensures safety as per DIN EN 13241-1, closing edge safety device with spiral cable.

Fitting Position
> Between the opening
> Behind the opening
 (for maximum width and height). This gives it the freedom to be fitted in the most complex locations regardless of the shape of the garage opening. Single and double garage door sizes are catered for meaning almost all requirements can be met. This makes it highly practical for owners of 4x4 vehicles or similar cars of a large nature who otherwise find problems driving into their garage. This installation style can be used to install the door externally, however, this will cause the motor handing and curtain to be reversed.





Installation Instructions are provided with every door.

Warranty

Hörmann products are manufactured to the highest quality standards and leave our factory only after rigorous quality testing. However, if you should have grounds for complaint, this section tells you what our door warranty offers, and how to go about making your claim.

In the unlikely event of a warranty claim becoming necessary, please contact the dealer or distributor who originally supplied your garage door. Your dealer should then supply details of the claim, together with a copy of the warranty card provided with the door and proof of purchase to the Product Services Department at Hörmann (UK) Ltd. To enable your claim under warranty to be processed as quickly as possible, you should provide the following details:

1 Your name, address and telephone number

2 Original invoice with date of purchase

3 Product description/door type and product number

4 Description of defect

An assessment of the claim will then be made. This may require Hörmann to inspect the product in-situ. In the event that there is no legitimate warranty claim under the terms specified herein, you may be liable for the costs of the inspection visit. We strongly recommend that you take note of the care and usage instructions displayed on the stickers on the back of your garage door, and on the page opposite, and that you follow these instructions throughout.

Hörmann (UK) Ltd Garage Door Warranty

Warranty Period The purchaser is granted a warranty covering the safe and reliable function of the Hörmann garage door for a period of 10 years from the date of purchase. A 5 year warranty applies to springs, wire cables, track rollers, hinges and guide rollers. The warranty period for replacement parts is 6 months or to the end of the current warranty period, whichever is longer. In the case of foilcoated timber-effect, a warranty of 5 years is granted, for timber and GRP doors a warranty of 2 years is granted on the door panels alone under the terms and conditions specified herein. The door mechanism and steel frame (if applicable) is covered by the 10 year warranty period.

Requirements

Warranty claims are only applicable in the country where the garage door was purchased. The product must have been purchased through our authorised distribution channels. The warranty only covers damage to the contract object. The fully completed warranty card together with the receipt of purchase correspondingly dated substantiates your right to claim under the warranty.

Performance

During the warranty period we undertake to rectify any and all defects to the Hörmann product which can be proved to be attributed to a material or manufacturing fault. We pledge at our discretion either to exchange the defective merchandise for faultless merchandise, repair it or allow a reduction in price. We do not accept costs for dismantling and installation nor for carriage.

Replaced parts become our property.

The warranty does not cover damage caused through:

• normal wear and tear

• improper installation

• negligent care and maintenance

• improper initial and subsequent operation

• negligent or wanton destruction

• external influences such as fire, water, salts, alkaline solutions, acids, abnormal environmental influences

• mechanical damage through improper transport and fitting

• priming and other surface protection treatments

• incorrect or too late applied surface protection treatments

• repair by non-qualified persons

• using non-Hörmann parts without the approval of the manufacturer

• removal of the product number or making it unidentifiable

Electric Operator Warranty

A separate 5 year warranty is granted on our electric operators. This includes operator mechanics, motor and motor control systems. A 2 year warranty is granted on radio equipment, accessories and system controls. There is no warranty on consumables (e.g. fuses, batteries, bulbs etc.).

User Information/Care

Finish - Steel Doors

The coating process applied to the door and chassis is environmentally friendly. Minor scratches or marks are not covered under the conditions of our warranty and should be repaired immediately to prevent corrosion and deterioration of the panel. Corrosive substances such as acids, alkalines, and salts, etc. should be cleaned from the door immediately; failure to do so will result in deterioration of the finish, which will not be covered under our warranty. Should deterioration of the finish start to occur you will need to repaint your door immediately. Prepare the surface lightly with wet and dry. Then treat with solvent based 2 pack epoxy wash primer and a normal commercial paint (cellulose paint must not be used). Hörmann steel doors are a finished product. They do not require re-painting on site. They are however not immune to damage, which can occur at any stage of the handling of the product from factory to site.

Finish - Timber Doors

Timber panels are coated with a neutralising base-stain. Doors must be stored upright, under cover, with wrapping intact, until wrapping is removed. As soon as the door is unwrapped, one coat of a good quality basecoat primer must be applied to both sides of the door. Immediately after installation, your timber doors require a further two coats of a good quality exterior wood finish on both sides. Initial application and periodic treatment should be carried out strictly in accordance with the woodstain manufacturer's instructions. Failure to follow these instructions will result in early deterioration of the timber panel.

Finish - GRP Doors

GRP door panels should periodically washed down using water. This should be done more frequently if fitted near the sea. Bird droppings will bleach the finish on GRP. and should be removed using water as soon as possible. GRP doors should not be painted over.

Paint Finish - Steel Doors

Minor surface damage can easily be repaired using touch up sprays or sticks without invalidating warranties.

Safe Operating and Maintenance of Hormann Garage Doors PDF >

Order size is the structural opening size (if fitting behind), deduct the guides and space needed for headroom from the opening dimension if fitting between.

Please allow additional 5mm space to each side of the door, in addition to the 97mm guides.



Hormann Rollmatic OD Roller Door Ordering Dimensions
