Carteck AutoTrend Standard Ribbed (20 Colour Options) ELECTRIC OPERATOR INCLUDED Insulated Sectional Door | Buy Carteck Sectional Steel Insulated Sectional Door Online

Carteck AutoTrend Standard Ribbed (20 Colour Options) ELECTRIC OPERATOR INCLUDED Steel Sectional Doors

Carteck

Sectional Doors Steel GEAR TYPE: Sectional

AutoTrend insulated sectional doors are made to measure as standard, available in 20 on trend colour choices and always come with the perfectly specified remote control electric opener, for convenient operation and security. These doors combine excellent quality, the most on-trend styles and colours, at our very best price, to give the very best solution for your garage.

Prices include electric motor with 2 no. 4 channel handsets
40mm thick insulated panels
Made to measure as standard
20 Colour Options - no extra cost

Choose Your Sizes

Width

Height Please Select Width First!

Description
Options
Specification
Installation
Warranty
Measure
Video
FAQs

The CarTeck AutoTrend Standard Ribbed design, electric operated sectional garage doors is designed with easy ordering in mind, offering a combination of excellent affordability, stunning curb appeal, and high levels of overall performance.

Double skinned insulated steel door panels with one of the best sectional door mechanisms on any door of this type, ultra low headroom requirements and maximum drive through clearance achieved when fully open using the electric operator.

Save hundreds of pounds with made to measure sizes at no extra cost and all the superb optional Trend colours available Free of charge!!

Here are some key features and benefits of the CarTeck AutoTrend Standard Ribbed:

Great Value

These high quality insulated sectional garage doors are specified and prepackaged by the manufacturer as an electric door, making them a great choice if you are looking for an electric operated high quality, high performance garage door.

Made to Order

AutoTrend range is custom-made, allowing you to get a product that perfectly fits your garage's dimensions with no additional cut down fees. You order to suit your exact size required at no extra cost. See our ‘Measure’ tab for full details on the ordering size references for these doors.

Colour Options

To compliment the 20 colour options you can choose a colour-matched frame to create a seamless and attractive finish. Moreover, all Carteck Trend colours are available at the same price as white, giving you more design choices.

Remote Control Electric Operation

The CarTeck AutoTrend range comes with one of 2 remote control openers - the CarTeck MOTOR L60 or L75, depending on the door size required. Both motor options include 2 no. 4 channel hand transmitters, making it easy and convenient to operate your garage door remotely (up to 4 doors from one transmitter)

The L75 includes a wireless wall switch as standard.

Either of these superb electric motors include powerful LED lighting as standard within the sleek motor head design. Super quiet and super powerful electric drive.

Everything you need to complete an insulated electric sectional door installation is included as standard, with optional extras for when you might be installing inbetween the garage aperture and not behind.

Choose Door Panel Colour Finish:
Select your preferred powdercoat colour finish from 20 of our most popular colours in either a smooth, woodgrain, Stucco or Micro profile finish, all at no additional cost.

Where the door is exposed to direct and lengthy sunlight darker colours should be avoided.

Frame legs and Head to match door colour:
Choose the colour you require for the outer steel frame system. Although many sectional garage doors are fitted behind the garage opening so you don’t see the sub frame you will still see the edge of the frame where it has a small return section. Standard colour is white and if any of the frame is showing or it is fitted inbetween you can contrast the door colour to the door panel colour if required.

Installation Position:
Tell us whether you are fitting the door behind or inbetween the structural opening.
Sectional garage doors were originally designed to install behind the structural opening of a garage but it is now possible to fit the door inbetween if required – when there are no returns, internal obstacles, etc.
The sizes for ordering should be carefully calculated when fitting inbetween the opening reducing the ordering width by the frame legs and head section along with a tolerance for fitting too. See our ‘Measure’ tab for full details.

Inbetween Opening Installation Kit:
If fitting the door inbetween the structural opening you will need this kit to secure the steel sub frame to the opening with the special set of bracketry.

Choose Remote Control Operator Model

The Autotrend electric motor is specified depending on the door size chosen.

Any doors up to 4877mm wide will have the MOTOR LM60 and doors over 4877mm will have the LM75 model as standard. You can select to have the LM75 motor drive for your door size if required and it does have the extra wall mounted wireless wall switch and an opening speed of 200mm/sec where the LM60 is 160mm/sec.

Both motor options include 2 no. 4 channel hand transmitters as standard. And both motors also have built in LED lighting neatly designed into the motor head unit for powerful courtesy lighting when using the electric motor. The lighting switches off automatically after a period of time.

The electric motor control units’ safety circuits monitor force levels many times every second. If the door encounters an obstruction, it is instantly sensed and the motor stops and reverses a short distance. Carteck doors and openers are independently tested and certified to all current safety legislation and carry a CE/UKCA mark.

Emergency External Release for garages with a second entrance:
If you have no other means of access into your garage then we strongly advise you have an emergency manual release mechanism. It is a key cylinder operated from the outside of the door which provides a manual facility to disengage the motor drive from the door enabling the door to be lifted manually when there is a power failure.

Optional Extras:
Handle - no external handle is fitted as standard. Will be required for a manually operated door.

High performance, insulated, vertically rising sectional door with unique tension spring balancing and springs located at the highest level for safety.

Fitted Carteck Sectional Door Performance:

Resistance to Wind Load: EN 12424 Class 2

Watertightness: EN 12425 Class 2

Air Permeability: EN 12426 Class 2

Thermal Transmittance: EN 13241 1.38 W/m2k

Operating Forces (hand operated): EN 12604 150 N

What’s in a number? The Carteck 40mm thick panels have an insulating value that has been independently tested to 0.56 W/m²K. The lower the value the better the insulating properties are for a door. The door panel on its own is not a figure we tend to quote because we know a door is more than just the one panel. Make sure you check any comparable insulated doors and whether it is the installed value or just a piece of the door panel.

Carteck quote the insulation value for a complete door (8’0” wide x 7’0” high) including the panel joints and weather strips. CarTeck Autotrend sectional has an insulation ‘U value’ of 1.38 W/m²K.- you won’t find better performance on any comparable garage door.

All door sizes available in all the Carteck Trend Colours at the same price as the standard white finish.

White - RAL 9016

Bling white – TT9016 (with micaceous iron ore particles glitter effect)

Ice Crystal Grey Aluminium

White Aluminium – RAL 9006

Grey Aluminium – RAL 9016

Light Grey – RAL 7035

Window Grey – RAL 7040

Quartz Grey – RAL 7039

Umbra Grey – RAL 7022

Slate Grey – RAL 7015

Anthracite Grey – RAL 7016

Anthracite Textured – RAL 7016 (only available on smooth door surface texture)

Satin Metallic – TT703 (a special satin metallic effect with micaceous iron ore particles)

Jet Black – RAL 9005

Steel Blue – RAL 5011

Moss Green – RAL 6005

Fir Green – RAL 6009

Flame Red – RAL 3000

Sepia Brown – RAL 8014

Cream – RAL 9011

Door fixing frame legs and head section are smooth and white colour (RAL9016) as standard.

Colour upgrade available to match or contrast door colour at additional cost

Rail Extensions

Rail extensions for the electric operator will automatically be added for all doors over 2500mm high. This is included within the price of the door.

If fitting between the opening, please deduct 180mm from the opening width to determine the ordering width and allow for your own tolerance in the sizes

Deduct 120mm for manual doors and 140mm for electric operation (unless the additional fitting bracket is purchased then 120mm applies) from the opening height to determine the ordering height.

In Between Structural Opening fit Sectional Doors - Link for info >

Please Note: Any door heights over 2250mm high - frames cannot be supplied undrilled.

Installation Instructions are provided with every door or can be found here.

CarTeck Motor Connector Alternatives

Door and mechanics

10-year manufacturer’s guarantee

• on panels against rust penetration from inside to outside

• against door panel separation of steel from foam

• on material and manufacturing flaws of all non-moving parts of the frame that are verifiably

unusable or whose usability is substantially compromised

• on floor seal, intermediate seals, side seals and lintel seal against rotting

5-year manufacturer’s guarantee

• on SLX & GSA Vision windows, rollers, hinges,

cable pulleys, cables and standard springs (opening/closing max. 5 times a day)

2-year manufacturer’s guarantee

• on polymer and aluminium window units

The guarantee does not apply to doors that are subjected to extreme conditions, e.g. corrosive influences resulting from use in a coastal climate with high salt content.

Carteck Motor Drive Guarantee

Applies to both the LM60 and LM75 motor drive units:

5-year manufacturer’s guarantee

• on mechanical defects, material and manufacturing flaws. (opening/closing max. 5 times a day)*

* Consumable Items are not included within warranty terms and conditions: hand transmitters, light bulbs, fuses & batteries.

If fitting between the opening, please deduct 180mm from the opening width to determine the ordering width.
Deduct 120mm for manual doors and 140mm for electric operation (unless the additional fitting bracket is purchased then 120mm applies) from the opening height to determine the ordering height.

Measuring guide for Carteck Autotrend Sectional Doors

Q: Why choose the Carteck AutoTrend package?

A: It's a perfect pre specified electric sectional door package when you need an electric sectional door at a bundle price and the colours and designs

(read more)

Friday 7th March 2025 at 12:00am

Q: How Do The Sectional Garage Doors fit to the Garage Opening?

A: Sectional garage doors are best fitted to the back of the structural opening but can be fitted inbetween the opening if required. All sectional ty

(read more)

Monday 11th March 2013 at 12:00am

Q: How safe are the electric operated doors?

A: All the remote control electric doors we sell are fully compliant with all the latest regulations and are CE marked. Many roller garage doors are sol

(read more)

Monday 21st November 2011 at 04:47pm

Q: Do you sell to House Developers?

A: Yes we have many major house developers purchasing garage doors regularly from us in quantities. We offer very competitive terms for quantities of

(read more)

Tuesday 11th October 2011 at 12:00am

Q: How are the doors delivered?

A: They are always delivered by either the manufacturer or ourselves in specialised transport vehicles. The smaller items such as the remote control o

(read more)

Wednesday 28th September 2011 at 12:00am

Q: Are installation instructions provided?

A: Most doors and electric operators are supplied with full printed installation instructions. Many PDF installation instructions can also be found

(read more)

Monday 5th September 2011 at 12:00am

View all in the Sectional Doors range >
