Gliderol Manual Roller Door with Full Hood (12 Colour Options) Aluminium Roller door - insulated
Gliderol Look at our customer reviews on trustpliot
Roller door - insulated Aluminium GEAR TYPE: Roller Shutter

The Gliderol Manual Insulated Roller Garage Doors are an intelligent design solution creating a smart and stylish door that features vertical travel, insulation and all round weather protection.


  • Manual or Remote Control Electric options
  • Easy DIY installation and lightweight, single skin curtain
  • Made to measure for the perfect fit
  • Safety obstacle detection as standard for electric door option
Choose Your Sizes
Web Price from: £1,260.00 Inc. VAT
£1,050.00 Ex. VAT

The Manual 77 Roller doors require 300mm of headroom space.

The Manual 77 Roller door has all the features of a Roll-A-Glide.

Gliderol roller doors are ideal for all shapes and sizes and can be fitted:
> Between the opening
> Behind the opening
(for maximum width and height). This gives it the freedom to be fitted in the most complex locations regardless of the shape of the garage opening. Single and double garage door sizes are catered for meaning almost all requirements can be met. This makes it highly practical for owners of 4x4 vehicles or similar cars of a large nature who otherwise find problems driving into their garage. This installation style can be used to install the door externally, however, this will cause the curtain to be reversed.

The Manual Roller Door opens vertically so you can park your car right up to the garage if you have a short driveway. You can also maximise space inside your garage as the door rolls up tightly and neatly above the lintel, allowing you to utilise all the roof space in your garage and also maximise drive through height for taller vehicles.

Low to medium security domestic garage and commercial use.

> Handsets supplied are pre-coded, no need to pair the handsets for easy set up

Manual roller doors have twin locking bars for equally effective locking operated by a simple key turn in the locking lath (outside and inside view). No handle is required as stops are provided.

Finishes available:
Fir Green
Light Ivory
Chartwell Green
Dark Blue
Purple Red
**door curtain only Graphite

Please Note: When ordering colour matched guides, we cannot guarantee the colour will be exact to the door colour finish.
For example when ordering a RAL7015 Slate Grey door guides will be supplied in RAL7016 Anthracite Grey.

*Colour matched guides are not available for the following door colours: Duck Egg Blue.

*It is possible that some of the bottom rail will be visible below the top of the opening when the door is in the open position.

A Note Concerning Colours: Door guides are available in colours matching the door curtain except laminate door colours (supplied in brown). Coloured guide rails are supplied as standard, however they may not exactly match the lath colour. The manufacturing process for the lath profile results in a textured finish, whilst all other coloured items (guides, bottom laths, lock laths, optional fascias and vision panels) are supplied in a satin finish so cannot be guaranteed to match exactly.

• Domestic/Residential use - 10 years corrosion free on door panel excludes paint surface rubbing or fading. (Mini Roller door has 1 year total warranty cover).
1 year on the lock and face plate, spring, bottom roller, weatherseal and polyglide, if fitted by an authorised Gliderol Distributor or Gliderol Technician.
3 month warranty on spring tension.
• Industrial/Commercial use - 1 year on the lock and face plate, spring, bottom roller, weatherseal and polyglide, if fitted by an authorised Gliderol Distributor or Gliderol Technician. 3 month warranty on spring tension.
The manufacturer strongly recommends that all Gliderol products be serviced by an authorised Gliderol Distributor or Gliderol Technician every 12 months to ensure longevity of the products’ life. Failure to do this may result in any warranty being invalid.
Warranties of 2 years electrical, 5 years tubular motors, 6 years mechanical and 10 years paint finish apply to all Gliderol doors (except Mini Roller
Doors see above).
Garage doors should be inspected upon installation and viewed in natural daylight (not direct sunlight) from a standard distance of 3 metres to view their overall appearance. From this distance the door panel should appear free from visible marks or distortion, stains, blemishes, indentations or scuffs.
Only marks visible from a distance of more than 3 metres will be considered under warranty.
Warranty Conditions
1. Subject to the under mentioned specific limitations and exceptions, the Manufacturer warrants all new doors, motors and electronic components of its
manufacture to be free from defect in workmanship under normal use and service and further warrants all installation carried out by the Manufacturer or by its nominated installers to be free from defects and workmanship its obligations hereunder being limited to making good any such defect PROVIDED THAT notice of any claimed defect in material workmanship in or resulting from installation of any door shall have been given to the Manufacturer within the period from date of installation as prescribed in the schedule hereto.
2. This warranty does not apply to any defect, loss or damage arising or caused directly or indirectly by or as a result of;
(i) Any masonry rendered or other surfaces cracking or collapsing during installation of the door.
(ii) Any defect or deterioration of timber including drying out after installation.
(iii) Any weakening or collapse of the structure to which the doors are affixed occurring any time after installation.
(iv) Any damage to or deterioration in the condition of the doors occurring in transit by customer nominated or appointed carrier or occurring after delivery and prior to installation.
(v) Any defect (including defects in component parts or accessories) rising from or attributable to the failure to carry out normal preventive maintenance or adjustment.
(vi) To any additional defect damage or deterioration arising from or attributable to the operation of the door after it is known to be defective.
(vii) Any door being installed within 800 metres of the sea or other body of water of equivalent or greater salt concentration or in an area subject to industrial fall out.
(viii) Any fault or surge in customer’s electricity supply.
(x) The door striking an immovable object during travel.
(xi) Garage doors should be inspected upon delivery and viewed in natural light (not direct sunlight) from a standard distance of 3 metres to view their overall appearance. From this distance the door panel should appear free from marks or distortion, stains, blemishes, indentations or scuffs. If any marks are only visible within 3 metres they will not be considered under warranty.
3. Items excluded from warranty;
(i) Batteries
(ii) Fuses
(iii) Globes
(iv) Sensitivity adjustments
(iiv) Minor factory repairs
4. While Gliderol doors are long lasting and hard wearing under normal conditions this warranty does not extend to inherent defects in steel or other material used in the manufacture. The Manufacturer will however, procure and assign to the customer the benefit of the warranty of the manufacturer of the steel or other material.
5. If Manufacturer has at request of customer procured painting, powder-coating or other surface application to its product this warranty does not extend to such painting, powder-coating or other surface application. For this purpose Manufacturer at all times acts as agent of customer. Manufacturer may as a
service to the customer but without any legal obligation to do so, assist customer to obtain redress in respect of any defect.
6. The Manufacturer reserves the right to touch up on site the paint finish and or pre-painted surfaces on its range of garage doors but no responsibility will be taken for the possibility of any paint rubs, scuffing etc on the internal wash coat finish or external painted surface.
7. Proof of purchase MUST be provided to the manufacturer at time of warranty claim. If proof is not available any warranty may be invalid.

The Manual Roller doors are ordered using the overall guide width and the guide height.
The overall height is the opening height plus the 300mm head plate.
The finished door ordering width is the opening width required plus 140mm (width of guides = 2 x 70mm).

As the Manual roller door can be fitted behind or in between the opening, then the calculations can be arrived at by different methods but all we need for ordering purposes is the overall width.

If fitting between the opening the over guide width of the door should be the narrowest measurement between the opening.
