The Seceuroglide LT is a stripped down version of the standard Seceuroglide.
It is designed to offer a fully compliant electric insulated roller garage door at a most competitive price in situations where security is not a particular issue.
The UK market has many roller door manufacturers selling low specification roller doors and many are not compliant with regulations but if price is your main consideration then this door will fit the bill.
The door still uses a bottom edge safety sensor rather than the illegal infra red beams and has 2 transmitters supplied for remote operation using 'rolling code' technology. The internal receiver and control box has a built in courtesy light operating when the door is opened and switching off automatically after a few minutes.
Courtesy Light: Making your garage a safer place when parking at night SeceuroGlide LT utilises the tried and tested SeceuroSense Plus control unit, which combines a courtesy light with both remote and push control functions.
SeceuroSense Plus Control Unit
> Integral alarm available as an optional extra, housed within the board.
> Improved cable and panel access points allow neater and more efficient installations and repairs.
> Long lasting LED courtesy light.
> Available with wired or wireless safety edge.
> Clear fault diagnosis on front cover with LED indicator lights.
> No more need for magnets with built-in ground exclusion.
> Ability to programme modes without the need to remove the front cover.
> Limit setting direct from the board through built-in test lead for ease of installation.
> Seperate lighting feed (up to 300W) integral to the board.
The curtain slats are a high quality double skinned, foam filled aluminium and available in various finished colours.
Internal manual override is standard for power failures and is on the same side as the motor unit which can be specified when ordering.
PLEASE NOTE: In the absence of A spring SWS apply an LT dummy end. This has an adjustable shaft in it. This is designed to be moved so the axle becomes the right size. This is stiff to pull but once its moved it moves freely. This then slots in to the bracket as normal.
The Seceuroglide LT Roller doors have 75mm guides up to 3000mm wide and 90mm guides for all doors over 3000mm wide. These guides come in white or brown as standard.
The 'up to' sizes referred to in the pricing are the overall door and guide width sizes including the side guides and the guide height required without the roll above. So to price a door for an opening 2300mm wide and 2200mm high assuming your are installing the roller door on the inside face of the garage opening you need to specify a door 2450mm over guides and 2200mm in guide height for pricing. Use the 'Up to 2600' for the width and 'Up to 2200' for the height in this example.
Operation:
Economy motor - remote control with bulk head courtesy light and two transmitters.
Safety bottom edge is included as standard.
Standard Colours:
Black - RAL9005
Graphite
Anthracite - RAL7016
Slate Grey - RAL7015
Silver Metallic - RAL9006
Light Grey (Agate Grey) - RAL 7038
White - RAL9016
Cream White - RAL9001
Light Beige - CS08B17
Ivory - RAL1015
Brown - RAL8014
Dark Brown - RAL8019
Fir Green - RAL6009
Moss Green - RAL6005
Chartwell Green
Duck Egg Blue
Navy Blue - RAL5011
Burgundy - RAL3004
Secure Locking
A unique end plate system secures the door shut every time and means the door cannot be lifted open.
Space Saving
Tighter, space-saving coiling leaves more space in your garage door for you.
SeceuroDrive
SeceuroDrive range of powerful motors make a reliable choice for the SeceuroGlide roller garage doors.
Power cuts - No Problem!
Every SeceuroGlide LT comes supplied with a simple manual override crank, ensuring you will never be accidentally locked in your garage – even in a power cut.
Courtesy Light
Making your garage a safer place when parking at night SeceuroGlide LT utilises the tried and tested SeceuroSense control unit, which combines a courtesy light with both remote and push control functions.
Remote Control
Open your door without leaving the car.
Peace of Mind
A special Vacation Mode activated by your hand transmitter prevents an intruder from operating the door from the inside using the receiver unit’s control panel.
Maximum Weather Protection
SeceuroGlide LT is engineered to block cold draughts and keep your garage warm and usable with guide rails that are lined with a dense brush strip and a shaped rubber seal on the bottom slat.
Installation Position
The Seceuroglide LT Roller doors are supplied with no box as standard. If Inbetween the Opening Installation is required, please note that some cladding may be required to cover the back side of the roll as this may be exposed with a between fix installation.
Wireless Safety Brake
Doors weighing over 26.5kg will be supplied with a wireless safety brake. This will prevent the door falling in the case of a motor failure.
LTs weighing less than 26.5kg will be supplied with a dummy end.
Sloping Bottom Slat
Please contact us to discuss requirements. This is designed to fit on inclines of up to 250mm.
Installation instructions are provided with every LT roller door ordered.
Please Note: Important Information when installing the Seceuroglide LT Roller Doors.
In the absence of the spring we apply an LT dummy end. This has an adjustable shaft in it. This is designed to be moved so the axle becomes the right size. This is stiff to pull but once its moved it moves freely. This then slots in to the bracket as normal.
For doors which have been supplied with a dummy end, the bearing will no longer be welded to the end. Instead, the bearing will now be located within the accessory box and will need to be installed manually.
To install the bearing, simply slide the bearing ontl the end of the dummy end shaft.
Details on the SeceuroDrive Motor Limit Setting Instructions can be watched here.
Please Note: Important Information when installing the Seceuroglide LT Roller Doors.
In the absence of the spring we apply an LT dummy end. This has an adjustable shaft in it. This is designed to be moved so the axle becomes the right size. This is stiff to pull but once its moved it moves freely. This then slots in to the bracket as normal.
